2.8 Undervoltage and Overvoltage Protection 27/59 (Optional)
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
132
10315 27-1-VpgTimeOut OUT 27-1-Vphg TimeOut
10316 27-2-VpgTimeOut OUT 27-2-Vphg TimeOut
10317 27-Vpg TRIP OUT 27-Vphg TRIP command
10318 27-1-Vpg PU A OUT 27-1-Vphg Pickup A
10319 27-1-Vpg PU B OUT 27-1-Vphg Pickup B
10320 27-1-Vpg PU C OUT 27-1-Vphg Pickup C
10321 27-2-Vpg PU A OUT 27-2-Vphg Pickup A
10322 27-2-Vpg PU B OUT 27-2-Vphg Pickup B
10323 27-2-Vpg PU C OUT 27-2-Vphg Pickup C
10325 27-1-Vpp Pickup OUT 27-1-Vphph Pickup
10326 27-2-Vpp Pickup OUT 27-2-Vphph Pickup
10327 27-Vpp PU AB OUT 27-Vphph Pickup A-B
10328 27-Vpp PU BC OUT 27-Vphph Pickup B-C
10329 27-Vpp PU CA OUT 27-Vphph Pickup C-A
10330 27-1-VppTimeOut OUT 27-1-Vphph TimeOut
10331 27-2-VppTimeOut OUT 27-2-Vphph TimeOut
10332 27-Vpp TRIP OUT 27-Vphph TRIP command
10333 27-1-Vpp PU AB OUT 27-1-Vphph Pickup A-B
10334 27-1-Vpp PU BC OUT 27-1-Vphph Pickup B-C
10335 27-1-Vpp PU CA OUT 27-1-Vphph Pickup C-A
10336 27-2-Vpp PU AB OUT 27-2-Vphph Pickup A-B
10337 27-2-Vpp PU BC OUT 27-2-Vphph Pickup B-C
10338 27-2-Vpp PU CA OUT 27-2-Vphph Pickup C-A
No. Information Type of In-
formation
Comments
