Siemens SIPROTEC 7SD80 User Manual

Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
334
A.1 Ordering Information and Accessories
A.1.1 Ordering Information
A.1.1.1 7SD80 V4.6
Line Differential Pro-
tection
6 7 8 9 10 11 12 13 14 15 16 Supplement
7SD80 ––F+
Measuring inputs, BO/BI, protection interface Pos. 6
1/6 19" housing; 4 x I, 3 BI, 5 BO (2 changeover contacts), 1 life status contact,
Protection interface optical fiber for monomode (24 km) (14.9 mi.)/multimode fiber (4 km) (2.5 mi.), LC duplex
connector
1
1/6 19" housing; 4 x I, 7 BI, 8 BO (2 changeover contacts), 1 life status contact,
Protection interface optical fiber for monomode (24 km) (14.9 mi.)/multimode fiber (4 km) (2.5 mi.), LC duplex
connector
2
1/6 19" housing; 4 x I, 5 BI, 8 BO (2 changeover contacts), 1 life status contact,
Protection interface copper (2-wire connection, twisted)
3
1/6 19" housing; 4 x I, 3 x V, 3 BI, 5 BO (2 changeover contacts), 1 life status contact,
Protection interface optical fiber for monomode (24 km)/multimode fiber (4 km), LC duplex connector
5
1/6 19" housing; 4 x I, 3 x V, 7 BI, 8 BO (2 changeover contacts), 1 life status contact,
Protection interface optical fiber for monomode (24 km)/multimode fiber (4 km), LC duplex connector
6
1/6 19" housing; 4 x I, 3 x V, 5 BI, 8 BO (2 changeover contacts), 1 life status contact,
Protection interface copper (2-wire connection, twisted)
7
Measuring inputs, default settings (BOLD) Pos. 7
I
ph
= 1 A / 5 A , I
N
= 1 A / 5 A 1
I
ph
= 1 A, I
Ns
(sensitive) = 0.001 A to 1.6 A / 0.005 A to 8 A 2
Auxiliary voltage (power supply) Pos. 8
DC 24 V / 48 V 1
DC 60 V / 110 V / 125 V / 220 V / 250 V, AC 115 V, AC 230 V 5
Construction Pos. 9
Surface-mounted housing, screw-type terminals B
Flush mounting case, screw-type terminals E
Region-specific language default settings and function versions Pos. 10
Region DE, IEC, language German (language can be changed) standard face plate A
Region world, IEC/ANSI, language English (language can be changed), standard face plate B
Region US, ANSI, language US - English (language can be changed), US face plate C
