A.9 Information List
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
378
534 Primary fault current Ib (Ib =) P.System Data 2 VI * On
Off
150 178 4 No
535 Primary fault current Ic (Ic =) P.System Data 2 VI * On
Off
150 179 4 No
536 Relay Definitive TRIP (Definitive
TRIP)
P.System Data 2 OUT ON ON LED BO 150 180 2 Yes
545 Time from Pickup to drop out (PU
Time)
P.System Data 2 VI
546 Time from Pickup to TRIP (TRIP
Time)
P.System Data 2 VI
561 Manual close signal detected
(Man.Clos.Detect)
P.System Data 2 OUT ON * * LED BO 150 211 1 No
562 CB CLOSE command for manual
closing (Man.Close Cmd)
P.System Data 2 OUT * * * LED BO 150 212 1 No
563 CB alarm suppressed (CB Alarm
Supp)
P.System Data 2 OUT * * * LED BO
590 Line closure detected (Line clo-
sure)
P.System Data 2 OUT * On
Off
* LED BO
916 Increment of active energy
(WpΔ=)
Energy -
917 Increment of reactive energy
(WqΔ=)
Energy -
1000 Number of breaker TRIP com-
mands (# TRIPs=)
Statistics VI
1027 Accumulation of interrupted
current Ph A (Σ Ia =)
Statistics VI
1028 Accumulation of interrupted
current Ph B (Σ Ib =)
Statistics VI
1029 Accumulation of interrupted
current Ph C (Σ Ic =)
Statistics VI
1030 max. fault current Phase A (Ia
max. =)
Statistics VI
1031 max. fault current Phase B (Ib
max. =)
Statistics VI
1032 max. fault current Phase C (Ic
max. =)
Statistics VI
1401 >50BF: Switch on breaker fail
prot. (>50BF on)
50BF BkrFailure SP * * * LED BI BO
1402 >50BF: Switch off breaker fail
prot. (>50BF off)
50BF BkrFailure SP * * * LED BI BO
1403 >BLOCK 50BF (>BLOCK 50BF) 50BF BkrFailure SP On
Off
* * LED BI BO 166 103 1 Yes
1404 >50BF use 3I0 threshold (>50BF
3I0>)
50BF BkrFailure SP On
Off
**LEDBIBO
1415 >50BF: External start 3pole
(>50BF Start 3p)
50BF BkrFailure SP On
Off
**LEDBIBO
1424 >50BF: Start only delay time T2
(>50BFSTRTonlyT2)
50BF BkrFailure SP On
Off
On
Off
* LED BI BO
1432 >50BF: External release (>50BF
release)
50BF BkrFailure SP On
Off
**LEDBIBO
1439 >50BF: External start 3p (w/o cur-
rent) (>50BF STARTw/oI)
50BF BkrFailure SP On
Off
**LEDBIBO
1440 Breaker failure prot. ON/OFF via
BI (BkrFailON/offBI)
50BF BkrFailure IntSP On
Off
**LEDBO
1451 50BF is switched OFF (50BF
OFF)
50BF BkrFailure OUT On
Off
* * LED BO 166 151 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
To Next Page
