Appendix
A.9 Information List
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
388
10250 59-1-Vphg Pickup C (59-1-Vpg
PU C)
27/59 O/U Volt. OUT * * * LED BO 73 135 2 Yes
10251 59-2-Vphg Pickup A (59-2-Vpg
PU A)
27/59 O/U Volt. OUT * * * LED BO 73 136 2 Yes
10252 59-2-Vphg Pickup B (59-2-Vpg
PU B)
27/59 O/U Volt. OUT * * * LED BO 73 137 2 Yes
10253 59-2-Vphg Pickup C (59-2-Vpg
PU C)
27/59 O/U Volt. OUT * * * LED BO 73 138 2 Yes
10255 59-1-Vphph Pickup (59-1-Vpp
Pickup)
27/59 O/U Volt. OUT * On
Off
* LED BO 73 55 2 Yes
10256 59-2-Vphph Pickup (59-2-Vpp
Pickup)
27/59 O/U Volt. OUT * On
Off
* LED BO 73 56 2 Yes
10257 59-Vphph Pickup A-B (59-Vpp
PickupAB)
27/59 O/U Volt. OUT * On
Off
* LED BO 73 57 2 Yes
10258 59-Vphph Pickup B-C (59-Vpp
PickupBC)
27/59 O/U Volt. OUT * On
Off
* LED BO 73 58 2 Yes
10259 59-Vphph Pickup C-A (59-Vpp
PickupCA)
27/59 O/U Volt. OUT * On
Off
* LED BO 73 59 2 Yes
10260 59-1-Vphph TimeOut (59-1-Vpp-
TimeOut)
27/59 O/U Volt. OUT * * * LED BO
10261 59-2-Vphph TimeOut (59-2-Vpp-
TimeOut)
27/59 O/U Volt. OUT * * * LED BO
10262 59-Vphph TRIP command (59-
Vpp TRIP)
27/59 O/U Volt. OUT * ON * LED BO 73 62 2 Yes
10263 59-1-Vphph Pickup A-B (59-1-
Vpp PU AB)
27/59 O/U Volt. OUT * * * LED BO 73 139 2 Yes
10264 59-1-Vphph Pickup B-C (59-1-
Vpp PU BC)
27/59 O/U Volt. OUT * * * LED BO 73 140 2 Yes
10265 59-1-Vphph Pickup C-A (59-1-
Vpp PU CA)
27/59 O/U Volt. OUT * * * LED BO 73 141 2 Yes
10266 59-2-Vphph Pickup A-B (59-2-
Vpp PU AB)
27/59 O/U Volt. OUT * * * LED BO 73 142 2 Yes
10267 59-2-Vphph Pickup B-C (59-2-
Vpp PU BC)
27/59 O/U Volt. OUT * * * LED BO 73 143 2 Yes
10268 59-2-Vphph Pickup C-A (59-2-
Vpp PU CA)
27/59 O/U Volt. OUT * * * LED BO 73 144 2 Yes
10270 59-1-3V0 Pickup (59-1-3V0
Pickup)
27/59 O/U Volt. OUT * On
Off
* LED BO 73 70 2 Yes
10271 59-2-3V0 Pickup (59-2-3V0
Pickup)
27/59 O/U Volt. OUT * On
Off
* LED BO 73 71 2 Yes
10272 59-1-3V0 TimeOut (59-1-
3V0TimeOut)
27/59 O/U Volt. OUT * * * LED BO
10273 59-2-3V0 TimeOut (59-2-
3V0TimeOut)
27/59 O/U Volt. OUT * * * LED BO
10274 59-3V0 TRIP command (59-3V0
TRIP)
27/59 O/U Volt. OUT * ON * LED BO 73 74 2 Yes
10280 59-1-V1 Pickup (59-1-V1 Pickup) 27/59 O/U Volt. OUT * On
Off
* LED BO 73 80 2 Yes
10281 59-2-V1 Pickup (59-2-V1 Pickup) 27/59 O/U Volt. OUT * On
Off
* LED BO 73 81 2 Yes
10282 59-1-V1 TimeOut (59-1-
V1TimeOut)
27/59 O/U Volt. OUT * * * LED BO
10283 59-2-V1 TimeOut (59-2-
V1TimeOut)
27/59 O/U Volt. OUT * * * LED BO
10284 59-V1 TRIP command (59-V1
TRIP)
27/59 O/U Volt. OUT * ON * LED BO 73 84 2 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
