Appendix
A.11 Measured Values
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
397
7761 Relay ID of 1st. relay (Relay ID) Measure Master - - - - - CFC CD DD
7762 I A (% of Operational nominal current) (I
A_opN=)
Measure Master - - - - - CFC CD DD
7763 Angle I A_remote <-> I A_local (ΦI A=) Measure Master - - - - - CFC CD DD
7764 I B (% of Operational nominal current) (I
B_opN=)
Measure Master - - - - - CFC CD DD
7765 Angle I B_remote <-> I B_local (ΦI B=) Measure Master - - - - - CFC CD DD
7766 I C (% of Operational nominal current) (I
C_opN=)
Measure Master - - - - - CFC CD DD
7767 Angle I C_remote <-> I C_local (ΦI C=) Measure Master - - - - - CFC CD DD
7769 V A (% of Operational nominal voltage) (V
A_opN=)
Measure Master - - - - - CFC CD DD
7770 Angle V A_remote <-> V A_local (ΦV A=) Measure Master - - - - - CFC CD DD
7771 V B (% of Operational nominal voltage) (V
B_opN=)
Measure Master - - - - - CFC CD DD
7772 Angle V B_remote <-> V B_local (ΦV C=) Measure Master - - - - - CFC CD DD
7773 V C (% of Operational nominal voltage) (V
C_opN=)
Measure Master - - - - - CFC CD DD
7774 Angle V C_remote <-> V C_local (ΦV C=) Measure Master - - - - - CFC CD DD
7781 Relay ID of 2nd. relay (Relay ID) Measure Slave - - - - - CFC CD DD
7782 I A (% of Operational nominal current) (I
A_opN=)
Measure Slave - - - - - CFC CD DD
7783 Angle I A_remote <-> I A_local (ΦI A=) Measure Slave - - - - - CFC CD DD
7784 I B (% of Operational nominal current) (I
B_opN=)
Measure Slave - - - - - CFC CD DD
7785 Angle I B_remote <-> I B_local (ΦI B=) Measure Slave - - - - - CFC CD DD
7786 I C (% of Operational nominal current) (I
C_opN=)
Measure Slave - - - - - CFC CD DD
7787 Angle I C_remote <-> I C_local (ΦI C=) Measure Slave - - - - - CFC CD DD
7789 V A (% of Operational nominal voltage) (V
A_opN=)
Measure Slave - - - - - CFC CD DD
7790 Angle V A_remote <-> V A_local (ΦV A=) Measure Slave - - - - - CFC CD DD
7791 V B (% of Operational nominal voltage) (V
B_opN=)
Measure Slave - - - - - CFC CD DD
7792 Angle V B_rem <-> V B_local (ΦV B=) Measure Slave - - - - - CFC CD DD
7793 V C (% of Operational nominal voltage) (V
C_opN=)
Measure Slave - - - - - CFC CD DD
7794 Angle V C_remote <-> V C_local (ΦV C=) Measure Slave - - - - - CFC CD DD
10102 Min. Zero Sequence Voltage 3V0 (3V0min =) Min/Max meter - - - - - CFC CD DD
10103 Max. Zero Sequence Voltage 3V0 (3V0max
=)
Min/Max meter - - - - - CFC CD DD
32204 Output power of the FO-Interface = (Output-
Power FO=)
Measure PDI - - - - - CFC CD DD
32205 Input power of the FO-Interface = (Input
Power FO=)
Measure PDI - - - - - CFC CD DD
32206 Budget of the FO-Interface = (Budget FO =) Measure PDI - - - - - CFC CD DD
32208 Attenuation of the Cu-Interface = (Attenua-
tionCu =)
Measure PDI - - - - - CFC CD DD
32209 Signal-to-noise ratio Cu-Interface = (StN
Ratio Cu=)
Measure PDI - - - - - CFC CD DD
32210 Send telegrams in the last second= (Send
Tel.sec=)
Measure PDI - - - - - CFC CD DD
32211 Good received telegrams in the last sec=
(Good Rec.sec=)
Measure PDI - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
