Siemens SIPROTEC 7SD80 User Manual

Functions
2.4 Backup Overcurrent
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
95
2635 67-TOC TD ANSI 0.50 .. 15.00 ; ∞ 5.00 67-TOC Time Dial for
ANSI characteristic
2636 51-B AddT-DELAY 0.00 .. 30.00 sec 5.00 sec 51-B Additional Time
Delay
2636 67-TOC AddTDel. 0.00 .. 30.00 sec 5.00 sec 67-TOC Additional Time
Delay
2637 51-B Inrush NO
YES
NO 51-B Inrush blocking
2637 67-TOC Inrush NO
YES
NO 67-TOC Inrush blocking
2638 51N-B PICKUP 1A 0.05 .. 4.00 A; ∞∞A 51N-B Pickup
5A 0.25 .. 20.00 A; ∞∞A
2638 67N-TOC PICKUP 0.05 .. 4.00 A; ∞∞A 67N-TOC Pickup thresh-
old
2639 51N-B TD IEC 0.05 .. 3.00 sec; ∞ 0.50 sec 51N-B Time Dial for IEC
characteristic
2639 67N-TOC TD IEC 0.05 .. 3.00 sec; ∞ 0.50 sec 67N-TOC Time Dial for
IEC characteristic
2640 51N-B TD ANSI 0.50 .. 15.00 ; ∞ 5.00 51N-B Time Dial for ANSI
characteristic
2640 67N-TOC TD ANSI 0.50 .. 15.00 ; ∞ 5.00 67N-TOC Time Dial for
ANSI char.
2641 51N-B AddTdelay 0.00 .. 30.00 sec 0.00 sec 51N-B Additional Time
Delay
2641 67N-TOC AddTDel 0.00 .. 30.00 sec 0.00 sec 67N-TOC Additional Time
Delay
2642 IEC Curve Normal Inverse
Very Inverse
Extremely Inv.
LongTimeInverse
Normal Inverse IEC Curve
2642 IEC Curve Normal Inverse
Very Inverse
Extremely Inv.
LongTimeInverse
Normal Inverse IEC Curve
2643 ANSI Curve Inverse
Short Inverse
Long Inverse
Moderately Inv.
Very Inverse
Extremely Inv.
Definite Inv.
Inverse ANSI Curve
2643 ANSI Curve Inverse
Short Inverse
Long Inverse
Moderately Inv.
Very Inverse
Extremely Inv.
Definite Inv.
Inverse ANSI Curve
Addr. Parameter C Setting Options Default Setting Comments
