Siemens SIPROTEC 7SD80 User Manual

Functions
2.4 Backup Overcurrent
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
97
7162 5X-B Pickup ØA OUT 50(N)/51(N) Backup O/C PICKUP Phase A
7163 5X-B Pickup ØB OUT 50(N)/51(N) Backup O/C PICKUP Phase B
7164 5X-B Pickup ØC OUT 50(N)/51(N) Backup O/C PICKUP Phase C
7165 5X-B Pickup Gnd OUT 50(N)/51(N) Backup O/C PICKUP GROUND
7191 50(N)-B1 PICKUP OUT 50(N)-B1 Pickup
7192 50(N)-B2 PICKUP OUT 50(N)-B2 Pickup
7193 51(N)-B PICKUP OUT 51(N)-B Pickup
7201 50-STUB PICKUP OUT 50-STUB Pickup
7211 5X-B TRIP OUT 50(N)/51(N)-B General TRIP command
7221 50(N)-B1 TRIP OUT 50(N)-B1 TRIP
7222 50(N)-B2 TRIP OUT 50(N)-B2 TRIP
7223 51(N)-B TRIP OUT 51(N)-B TRIP
7235 50-STUB TRIP OUT 50-STUB TRIP
7250 67(N)-B1 PICKUP OUT 67(N)-B1 Pickup
7251 67(N)-B2 PICKUP OUT 67(N)-B2 Pickup
7252 67(N)-TOC PICK. OUT 67(N)-TOC Pickup
7253 67(N) TRIP OUT 67(N) General TRIP command
7254 67(N)-B1 TRIP OUT 67(N)-B1 TRIP
7255 67(N)-B2 TRIP OUT 67(N)-B2 TRIP
7256 67(N)-TOC TRIP OUT 67(N)-TOC TRIP
7257 67 forward ØA OUT 67 Phase A forward
7258 67 forward ØB OUT 67 Phase B forward
7259 67 forward ØC OUT 67 Phase C forward
7260 67N forward GND OUT 67N Gnd forward
7261 67 reverse ØA OUT 67 Phase A reverse
7262 67 reverse ØB OUT 67 Phase B reverse
7263 67 reverse ØC OUT 67 Phase C reverse
7264 67N reverse GND OUT 67N Gnd forward
7265 67(N) forward OUT 67(N) forward
7266 67(N) reverse OUT 67(N) reverse
7267 >67(N) InstTRIP SP >67(N) BackupO/C InstantaneousTrip
17530 67(N) BLOCK OUT 67(N) Backup O/C is BLOCKED
17531 67(N) ACTIVE OUT 67(N) Backup O/C is ACTIVE
17532 67(N)-B2 OFF OUT Backup O/C stage 67(N)-B2 is sw. OFF
17533 67(N)-B1 OFF OUT Backup O/C stage 67(N)-B1 is sw. OFF
17534 67(N)-TOC OFF OUT Backup O/C stage 67(N)-TOC is sw. OFF
17535 67(N) PICKUP OUT 67(N) Backup O/C PICKED UP
17536 67 Pickup ØA OUT 67 Backup O/C PICKUP Phase A
17537 67 Pickup ØB OUT 67 Backup O/C PICKUP Phase B
17538 67 Pickup ØC OUT 67 Backup O/C PICKUP Phase C
17539 67N Pickup Gnd OUT 67N Backup O/C PICKUP GROUND
No. Information Type of In-
formation
Comments
