Parameter Listing - Bay Unit
369
7SS52 V4 Manual
C53000-G1176-C182-3
4402 CB TRIP Tests Circuit breaker trip test 1pole L2
4403 CB TRIP Tests Circuit breaker trip test 1pole L3
4404 CB TRIP Tests Circuit breaker trip test 3pole
4501 Com. CU Tests Switching bay out of service
4502 Com. CU Tests Switching bay in service
4503 Com. CU Tests Switching bay in maintenance
4601 CT-POLARITY Tests Turn around polarity of current
transformer
4701 BI1-STATE Tests Show state of binary input 1
... ... ... ...
4720 BI20-STATE Tests Show state of binary input 20
4801 TRIP RELAY1 Tests Switch on trip relay 1
4802 TRIP RELAY1 Tests Switch off trip relay 1
4803 TRIP RELAY2 Tests Switch on trip relay 2
4804 TRIP RELAY2 Tests Switch off trip relay 2
4805 TRIP RELAY3 Tests Switch on trip relay 3
4806 TRIP RELAY3 Tests Switch off trip relay 3
4807 TRIP RELAY4 Tests Switch on trip relay 4
4808 TRIP RELAY4 Tests Switch off trip relay 4
4809 TRIP RELAY5 Tests Switch on trip relay 5
4810 TRIP RELAY5 Tests Switch off trip relay 5
4811 SIGN.RELAY1 Tests Switch on signal relay 1
4812 SIGN.RELAY1 Tests Switch off signal relay 1
4901 FAULT REC. Tests Initiation of fault recording
5604 Trip No = CB operat. statis-
tics
Number of trip commands issued
5607
ΣIL1/In= CB operat. statis-
tics
Summated current tripped IL1/In
5608
ΣIL2/In= CB operat. statis-
tics
Summated current tripped IL3/In
5609
ΣIL3/In= CB operat. statis-
tics
Summated current tripped IL2/In
5610 IL1/In= CB operat. statis-
tics
Last trip current IL1/In
5611 IL2/In= CB operat. statis-
tics
Last trip current IL2/In
5612 IL3/In= CB operat. statis-
tics
Last trip current IL3/In
5701 IL1 = Operational
measured values
Current in phase L1 = %In
5702 IL2 = Operational
measured values
Current in phase L2 = %In
5703 IL3 = Operational
measured values
Current in phase L3 = %In
5704 IE = Operational
measured values
Earth current = %In
Addr. Setting Title Function Setting Options Default Setting Comments
