Appendix
370
7SS52 V4 Manual
C53000-G1176-C182-3
5705 IL1 = Operational
measured values
Current in phase L1 = A
5706 IL2 = Operational
measured values
Current in phase L2 = A
5707 IL3 = Operational
measured values
Current in phase L3 = A
5708 IE = Operational
measured values
Earth current = A
5709 IL1 = Operational
measured values
Current in phase L1 = %Ino
5710 IL2 = Operational
measured values
Current in phase L2 = %Ino
5711 IL3 = Operational
measured values
Current in phase L3 = %Ino
5712 IE = Operational
measured values
Earth current = %Ino
5713 IDL1 = Operational
measured values
Bus Zone: Idiff L1 = %Ino
5714 IDL2 = Operational
measured values
Bus Zone: Idiff L2 = %Ino
5715 IDL3 = Operational
measured values
Bus Zone: Idiff L3 = %Ino
5716 ISL1 = Operational
measured values
Bus Zone: Istab L1= %Ino
5717 ISL2 = Operational
measured values
Bus Zone: Istab L2= %Ino
5718 ISL3 = Operational
measured values
Bus Zone: Istab L3= %Ino
5719 f [Hz] = Operational
measured values
Frequency f [Hz] =
6101 BINARY INPUT 1 Marshalling Binary input 1
... ... ... ...
6120 BINARY INPUT 20 Marshalling Binary input 20
6201 SIGNAL RELAY 1 Marshalling Signal relay 1
6301 LED 1 Marshalling LED 1
... ... ... ...
6316 LED 16 Marshalling LED 16
6401 TRIP RELAY 1 Marshalling Trip relay 1
... ... ... ...
6405 TRIP RELAY 5 Marshalling Trip relay 5
7101 Language Integrated Opera-
tion
DEUTSCH
ENGLISH
FRANCAIS
ESPANOL
ITALIANO
PYCCK.
ENGLISH Language
7120 OPER.1st L. Integrated Opera-
tion
IL1, IL2, IL3, IE
I-DIFF. L1, I-DIFF. L2,
I-DIFF. L3
I-RESTR. L1, I-RESTR.
L2, I-RESTR. L3
IL1 Display of measured values in the
1st line of the quiescent-state indi-
cation in 4-line mode
7121 OPER.1st L. Integrated Opera-
tion
SECONDARY
PRIMARY
NORMALIZED
SECONDARY Display of measured values in the
1st line as primary or secondary
(percent) values
Addr. Setting Title Function Setting Options Default Setting Comments
