Configuration Notes
69
7SS52 V4 Manual
C53000-G1176-C182-3
Figure 4-18 Object properties of the transformer T1 from the example given in Figure 4-17,
page 68
Figure 4-19 Example for the configuration of a 2-bay coupler with two CTs
Please note the crosswise assignment of the transformers.
Bay Bay unit
E01
E02a
E02b
E03
E04
BU 1
BU 2
BU 3
BU 4
BU 5
