SINAMICS G150
Engineering Information
SINAMICS Engineering Manual – November 2015
Ó Siemens AG
305/528
Output power
at
400V / 500V / 690 V
Rated output current
or
current derating factor
with pulse frequency of
Current derating factor
with pulse frequency of
1.25 kHz 2.0 kHz 2.5 kHz 4.0 kHz 5.0 kHz 7.5 kHz 8.0 kHz
660 V – 690 V 3AC
75 kW 85 A 93 % 89 % 71 % 60 % 40 %
90 kW 100 A 92 % 88 % 71 % 60 % 40 %
110 kW 120 A 92 % 88 % 71 % 60 % 40 %
132 kW 150 A 90 % 84 % 66 % 55 % 35 %
160 kW 175 A 92 % 87 % 70 % 60 % 40 %
200 kW 215 A 92 % 87 % 70 % 60 % 40 %
250 kW 260 A 92 % 88 % 71 % 60 % 40 %
315 kW 330 A 89 % 82 % 65 % 55 % 40 %
400 kW 410 A 89 % 82 % 65 % 55 % 35 %
450 kW 465 A 92 % 87 % 67 % 55 % 35 %
560 kW 575 A 91 % 85 % 64 % 50 % 35 %
710 kW 735 A 87 % 79 % 64 % 55 % 25 %
800 kW 810 A 83 % 72 % 61 % 55 % 35 %
1000 kW 1070 A
1)
91 % 85 % 64 % 50 % 35 %
1350 kW 1360 A
1)
87 % 79 % 64 % 55 % 25 %
1500 kW 1500 A
1)
83 % 72 % 61 % 55 % 35 %
1750 kW 1729 A
1)
92 % 87 % 67 % 55 % 33 %
1950 kW 1948 A
1)
91 % 86 % 64 % 50 % 30 %
2150 kW 2158 A
1)
87 % 79 % 55 % 40 % 25 %
2400 kW 2413 A
1)
87 % 79 % 55 % 40 % 25 %
2700 kW 2752 A
1)
91 % 86 % 64 % 50 % 30 %
1)
G150 parallel connection / the specified currents represent the total current of all inverter sections
SINAMICS G150: Permissible output current (current derating factor) as a function of pulse frequency (continued)
Pulse frequency Maximum attainable output frequency (rounded numerical values)
1.25 kHz 100 Hz
2.00 kHz 160 Hz
2.50 kHz 200 Hz
≥ 4.00 kHz 300 Hz
Maximum attainable output frequency as a function of pulse frequency
in operation with factory-set current controller clock cycles
Permissible output current as a function of ambient temperature
SINAMICS G150 converters and associated system components are rated for an ambient temperature of 40 C and
installation altitudes of up to 2000 m above sea level. The output current of SINAMICS G150 converters must be
reduced (current derating) if they are operated at ambient temperatures above 40 C. G150 cabinet units are not
permitted to operate at ambient temperatures in excess of 50 C. The tables below state the permissible output
current as a function of the ambient temperature for different degrees of protection.
Installation altitude
above sea level
Current derating factor
at an ambient temperature (inlet air) of
m 20 °C 25 °C 30 °C 35 °C 40 °C 45 °C 50 °C
0 ... 2000 100 % 93.3 % 86.7 %
Current derating factors as a function of ambient temperature (inlet air) for SINAMICS G150 converter cabinet units
in degrees of protection IP20, IP21, IP23 and IP43
Installation altitude
above sea level
Current derating factor
at an ambient temperature (inlet air) of
m 20 °C 25 °C 30 °C 35 °C 40 °C 45 °C 50 °C
0 ... 2000 100 % 93.3 % 86.7 % 80.0 %
Current derating factors as a function of ambient temperature (inlet air) for SINAMICS G150 converter cabinet units
in degree of protection IP54
