SINAMICS G150
Engineering Information
SINAMICS Engineering Manual – November 2015
Ó Siemens AG
326/528
Note:
By contrast with the S120 Line Modules and S120 Motor Modules of the SINAMICS S120 modular system (Chassis
and Cabinet Modules) with which a parallel connection can be created using up to four identical individual modules,
the G150 parallel converter is a ready-to-connect converter cabinet unit which is constructed of two lower-output
SINAMICS G150 converter cabinet units or of two Basic Line Modules and two or three Motor Modules. The parallel
converter is ordered as a unit under a single order number. The technical data stated in the catalogs and the tables in
this engineering manual therefore generally refer to the complete G150 parallel converter and already include the
current and power derating factors required for parallel connections. Owing to the length dimensions of the parallel
converters, the G150 is delivered in transport units.
The following table shows the power spectrum of SINAMICS G150 parallel converters. The last column of the table
states (for information only) the individual components from which the relevant parallel converters are built.
Rated
output current
Low overload High overload Order number The parallel converter is based on
following individual components
P
L
current I
P
H
Base load
current I
[A] [kW] [A] [kW] [A]
Line supply voltage 380 V – 480 V 3AC
1120 630 1092 500 850 6SL3710-2GE41-1AA3 2 x G150 / 315 kW / 605 A
1380 710 1340 560 1054 6SL3710-2GE41-4AA3 2 x G150 / 400 kW / 745 A
1560 900 1516 710 1294 6SL3710-2GE41-6AA3 2 x G150 / 450 kW / 840 A
Line supply voltage 500 V – 600 V 3AC
860 630 836 560 770 6SL3710-2GF38-6AA3 2 x G150 / 315 kW / 465 A
1070 710 1036 630 950 6SL3710-2GF41-1AA3 2 x G150 / 400 kW / 575 A
1360 1000 1314 800 1216 6SL3710-2GF41-4AA3 2 x G150 / 500 kW / 735 A
Line supply voltage 660 V – 690 V 3AC
1070 1000 1036 900 950 6SL3710-2GH41-1AA3 2 x G150 / 560 kW / 575 A
1360 1350 1314 1200 1216 6SL3710-2GH41-4AA3 2 x G150 / 710 kW / 735 A
1500 1500 1462 1350 1340 6SL3710-2GH41-5AA3 2 x G150 / 800 kW / 810 A
1729 1750 1720 1500 1547 6SL3710-2GH41-8EA3 2 x BLM / 1100 kW +
2 x MoMo / 900 kW / 910 A
1948 1950 1940 1750 1742 6SL3710-2GH42-0EA3 2 x BLM / 1100 kW +
2 x MoMo / 1000 kW / 1025 A
2158 2150 2150 1950 1930 6SL3710-2GH42-2EA3 2 x BLM / 1100 kW +
2 x MoMo / 1200 kW / 1270 A
2413 2400 2390 2150 2158 6SL3710-2GH42-4EA3 2 x BLM / 1500 kW +
2 x MoMo / 1200 kW / 1270 A
2752 2700 2685 2400 2463 6SL3710-2GH42-7EA3 2 x BLM / 1500 kW +
3 x MoMo / 1000 kW / 1025 A
Power spectrum of SINAMICS G150 parallel converters
Since all SINAMICS G150 parallel converters always consist of two identical rectifiers on the line side, the rectifiers
can operate as either a 6-pulse or a 12-pulse bridge circuit. The harmonic effects on the supply system are
significantly lower in 12-pulse operation than in 6-pulse operation (see section "Harmonic effects on supply system" in
chapter "Fundamental Principles and System Description").
Different decoupling measures need to be considered on the line side depending on whether the parallel connection
is a 6-pulse or 12-pulse circuit.
Different decoupling measures also need to be considered on the motor side depending on the type of winding
system of the motor (electrically isolated winding systems or one common winding system) and the number of
inverters in the G150 parallel connection (two or three).
For this reason, the boundary conditions to be considered at the line side and the motor side are discussed in more
detail below.
