Note: if the analog channel or the math function is cut off (waveforms do not
display on the screen completely), the resulting math will also be cut off.
Math
The oscilloscope supports many math operations between analog channels
including addition (+), subtraction (-), multiplication (*), division (/), FFT,
differential (d/dt), integral (∫dt), square root (√). The resulting math waveform is
displayed in white and labeled with “M”. You can use cursors to measure it.
The contents of this chapter:
Units for Math Waveforms
Math Operators
