Navigate
SDS1000X-E(4-channel） and SDS1000X-U provide three navigate type: Search
Event, Time, History Frame.
Time Navigate
1. Press the Navigate on the front panel to enter the NAVIGATE function menu.
2. Press the Type softkey In the NAVIGATE function menu, then select Time.
3. There are two ways to navigate time.
a. Press the Time softkey, then, turn the Universal Knob to select the desired
value or press the Universal Knob then enter the value by the pop
keyboard.
b. Press the navigation keys ◀■▶ on the front panel to play backward, stop,
or play forward in time. You can press the ◀ or ▶ keys multiple times to
speed up the playback. There are three speed levels: Low Speed, Medium
Speed, and High Speed.
History Frame Navigate
When the History function is enabled, you can use the navigation controls to play
through the acquired frames.
1. Press the Navigate on the front panel to enter the NAVIGATE function menu.
2. Press the Type in the Navigate Menu, then select History Frame.
3. Press the Frame Num softkey, then there are two ways to navigate history
frames.
a. Turn the Universal Knob to select the desired number or press the
Universal Knob then enter the number by the pop keyboard.
b. Press the navigation keys ◀■▶ on the front panel to play backward, stop,
or play forward.
