SDS1000X-E&SDS1000X-U User Manual
192
Figure 118 AWG Update Interface
After the updating is finished, the AWG will automatically disconnected and
display a message “Update completed, please reconnect AWG device!”
Remove Device
Press Utility→NextPage4/4→AWG→Remove Device, and the oscilloscope interface
display "AWG device removed!", the device can be pulled.
Note：Don't cut off the power during the AWG is being updated！
