Measure
The oscilloscope provides measurements of 36 waveform parameters and the
statistics. It contains voltage, time and delay parameters.
Voltage and time parameters are under Type option. The results of the last four
selected measurements are displayed at the bottom of screen and above the menu.
Delay parameters are under the All Measure submenu. Set the Delay option to On
to display all the delay parameters.
The contents of this chapter:
 Type of measurement
 Automatic measurement
 All measurement
 Gate measurement
 Clear measurement
