SDS1000X-E&SDS1000X-U User Manual
191
and serial number. After finished, press the return softkey to exit the system
information page.
Figure 117 AWG System Information Interface
Update
The software version file of the AWG can be updated directly via U-disk. Follow the
steps below:
Insert U-disk with firmware update file (*.ads) to USB host interface on the front
panel of the oscilloscope. Than a message “USB Flash Drive detected!” will
be displayed.
Press Utility →NextPage4/4→ AWG →System →Update.
Expand the U disk directory, Select the firmware file (*.ads), then press the
Press to update, an upgrade progress bar will be display on the interface.
