SDS1000X-E&SDS1000X-U User Manual
208
4) Press the Cursors soft key to enter the CURSORS menu. See the chapter
"Cursor" for details.
3. Press the Data softkey to enter the DATA menu. The data menu displays the
configurations of bode plot measurement results.
Figure 133 DATA Menu
1) Press the List softkey repeatedly to turn the Bode plot data list on or off.
After turning on the list, press the Scroll soft key and turn the Universal
Knob to select the frequency point, as shown below.
Figure 134 Bode Plot List On
2) Press Save softkey (Recall softkey) to enable the bode plot save (recall)
function. See the chapter “Save and Recall” for details.
