8 Man_user_AI80_r2
2.2 Buttons
Manoeuvring in the display: move the "viewport" up, down, left and
right using the ARROW buttons in order to display the text. A display
page is not limited to 4x20 characters. The manoeuvring allows the
user to move a "viewport" up/down and sideways in order to display
the entire text. This "window" of 4x20 characters used for viewing the
text, is called a viewport in this manual.
- Main Menu ------------
Active alarms
Redundancy
Settings ▼
SMS
Downperiods
System
Entering data: by pressing the EDIT button when an editable
parameter is selected allows input of text, numbers and symbols. Enter
text by pressing the character buttons, enter numbers by first pressing
SHIFT followed by the selected number. Press SHIFT again to return
to character buttons. Enter SPACE and other non-alphabetic symbols
by using the Number 1 button in alpha numeric mode.
Selecting: by using the ARROW buttons the user can move the cursor
when the correct parameter has been selected. Press OK to view or
enter submenus.
Buttons are PRESSED to select the relevant functionality and HELD
to select alternative functionality when relevant. Some buttons have
toggle functionality that is triggered by repeatedly pressing this
button.
By pressing the buttons below the user can enter text or numbers.
Switch between characters and numbers by pressing the
SHIFT button.
SPACE and non-alphabetic symbols can be entered by using the
Number 1 button. When not in Edit mode, the Number 0 button
toggles the backlight on/off.
1 2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PQRS
8
TUV
9
WXYZ
0
OFF
Viewport
Display page
