24 Man_user_AI80_r2
- Software Upgrade ----
Backup Successful
Please turn off unit
and insert new CF card
If performing software upgrade, turn off power and
insert CF card with new software before power-on of
the unit. Upon power-on, the configuration data are
automatically retrieved. Thus enabling software
upgrade without loss of configuration data.
If software upgrade is initiated by accident, simply
cycle power, to restart the unit.
NOTE! Software Upgrade should only be performed by
qualified personnel.
Diagnostics
- DIAGNOSTICS --------
VHF
Serial
Config file
The Diagnostics page shows the submenus
available to display, test and debug the
communication links and configuration settings.
- VHF ----------------
Tx ChA: MSG01 00:01
Tx ChB: MSG03 00:20
Rx ChA: MSG04 00:03 ▼
Rx ChB: MSG17 00:02
Tx DSC: NONE
Rx DSC: NONE
VHF
The VHF page displays which messages have been
transmitted and received on the VDL interface.
This page will automatically be updated every
second.
- Serial --------------
PI in : NONE 59:59
PI out : VDO 00:01
RTCM in : NONE 59:59 ▼
RTCM out: NONE 59:59
Sens1 in: NONE 59:59
Serial
Diagnostics of serial interfaces, type of sentence
and time elapsed since last transmission/reception
on each port.
- Config File -------- ►
!***********************
!*
!* Seatex AISBS▼
Config.File
Read-out of config. file. For service purposes
only.
