2.3 Using display and keypad
Manoeuvring and selecting
The uppermost line on the viewport is the page title. Select wanted
line with the UP/DOWN ARROW buttons. The selected line is marked
with an underscore character on the right side of the line content.
- Settings -------------
Nav.Status
Voyage related
Gyro calibration ▼
Static data
VHF
LR
Serial
PIN
▲ ▼ symbols indicate that a page has more than three lines of
content. Manoeuvre the viewport up and down with the ARROW
buttons.
◄ ► symbols indicate that the page contains lines with more than 20
characters. Manoeuvre the viewport left and right with the LEFT and
RIGHT ARROW buttons respectively.
Select a highlighted item by pressing the OK button.
Dialogue boxes
Dialogue boxes inform the user about events or state changes that
require user interaction. Such events are:
• Alarms
• SMS
• Enter PIN
• Edit error
• Item Help
Dialogue boxes are shown as whole pages, i.e. they are displayed in
the whole "viewport", and forces the user to press one or more buttons
to continue. The dialogue box indicates the keys required to exit the
dialogue box. This is indicated by the button name encapsulated in
square brackets.
The bold lined rectangle
illustrates what is shown on
the screen.
