16 Man_user_AI80_r2
*** LR Req
123456789:ABCEFIOPUW
[OK] to send
[Cancel] to deny
New LR
When an LR request arrives, a dialogue box prompts
the user to send or deny the requested information.
The dialogue box provides information about
requester's MMSI and the codes for requested
information (e.g. C means Position). The Info
functionality can describe this upon request. If the
user does not respond within the given timeout, the
information is denied to the requester. All LR requests
are also stored in LR history. Press OK to send the
information or CANCEL to reject the information.
123456789:ab
- LR requests -------
111111111: abcef ▲
222222222: ABCEFIOPUW
333333333: a ▼
444444444: ce
555555555: abc
666666666: ABCE
777777777: puw
LR requests
LR requests contains history of the last 30 requests.
This is also a read only page. The figure shows a list
with eight requests. First the MMSI of the requestor
followed by the information requested. If the
requested information is displayed with small letters,
the information is provided, otherwise denied.
Dynamic data
- Dynamic Data ------
LAT: 063°36'31.44N
LON: 010°24'13.73E
COG: 000.00° ▼
SOG: 000.00kn
HDG: N/A
ROT: N/A
EPFD: GPS
The Dynamic Data page shows sensor readings. This
is a read only page. Press
CANCEL to return to Main
Menu.
