User interface
Man_user_AI80_r2 11
To facilitate recognition, the uppermost line on a dialogue box is
composed of a start pattern of three * signs, and a post fixed pattern of
* until the end of the line. A dialogue box prompting for PIN code
appears like the figure below.
*** PIN Code ***********
*B
[Cancel] [OK]
Editing
The user can edit a variable by pressing EDIT when highlighted. The
value of the current variable is stored and the user can start editing the
data. The user selects characters by repeatedly pressing numeric
buttons,
- Static data ---------- - Static data ----------
MMSI: 000000001 MMSI: 000000002
Pos Source: Internal Pos Source: Internal
SurveyedLat: 00°00'▼
1 x
2
ABC
SurveyedLat: 00°00'▼
or, in cases were there are predefined variables, chooses from a list of
these by using the UP or DOWN ARROW buttons.
- Serial -------------- - SETTINGS -------------
Sensor 1: 4800 Sensor 1: 4800
RTCM : 9600! RTCM : 4800!
PI : 38400 ▼
1 x
2
ABC
PI : 38400 ▼
The button between the displays indicates that pressing this button
when in the screen to the left, will result in the changes seen in the
screen to the right.
After editing, press OK to confirm changes and exit Edit mode, or
press CANCEL to discard changes. If the input exceeds the horizontal
length of the display (20 chars), it automatically scrolls. When editing
is completed and OK is pressed, it scrolls back. Values are saved by
holding the OK button pressed.
