Software setup procedure
Man_user_AI80_r2 33
3 SOFTWARE SETUP PROCEDURE
3.1 General
The AI80 system is set up with factory settings during testing. The
software setup must be performed as a part of the AI80 installation
procedure.
The software setup is performed from sub-menus available from the
Main Menu page, activated by pressing the VIEW button. The
respective Main Menu pages are shown below.
- MAIN MENU ------------
Alarms and LR
Dynamic data
Settings ▼
SMS
Downperiods
Chn.Management
System
This is the Main Menu page for the AI80 with sub-
menus. All settings that need to be changed can be
found in the Settings sub-menu.
For manoeuvring in the menus and for entering
data, refer to AI80 user interface on page 7.
Note ! The software settings may be protected by a security code. When
entering parameters defined with a security level other than 0, the
access code has to be entered before these settings can be changed.
Refer Security settings AI80 in the next pages and page 61.
3.2 Security settings AI80
- Settings ----------
Nav.Status
Voyage related
Gyro calibration
Static data
VHF ▲
LR
Serial
PIN
Security PIN code
All entries on this page are protected by a PIN code.
Initially, a default authorisation code is used for
altering data fields in the Settings page. The default
PIN code is: 1234. We recommend to change to a
vessel specific PIN code.
Enter new four digit PIN code by selecting PIN and
PIN: **** on the Settings menu.
Note! If the PIN code is lost, contact Customer
Support for help to retrieve the correct PIN code.
