14 Man_user_AI80_r2
Ship list view
00.12 023 PRINSESS OF THE SEA
RANGE BRG NAME
01.11 025 FOSNINGEN▲
02.10 160 NORDLYS
02.22 343 SKIPPER V▼RSE
03.21 299 KONG SVERRE
06.44 164 BS:25791239
06.55 279 ATN:MUNKHOLMEN
07.00 234 SAR:123456789
The default main page of the system is
called Ship list view and contains
information about nearby vessels. Range,
Bearing and Name (MMSI if name not
available) are shown.
BS: in front of the MMSI indicates an AIS
base station.
ATN: in front of the ship name indicates an
Aids To Navigation target.
SAR: in front of an MMSI number indicates
a SAR aircraft.
Name: VANNINA
MMSI: 136547932
CallSign: CA122
LAT: 063°36'31.44N
LON: 010º24'13.73E
NavStatus: Under way using en
Dest: Lia
ETA: 2231100
- SHIP DATA ----------------
Draught: 5.00 m
EPFD: GPS
ACC: LOW ▼
RAIM: off
Time: 11:54:27
COG: 170.00º
SOG: 010.00 kn
HDG: N/A
ROT: N/A
OnBoard: 12
IMO: 123
Type: 2
Keel: 10
LengthA: 12
LengthB: 2
LengthC: 12
LengthD: 2
DTE: Connected
If the operator presses OK for the selected
ship, a page displaying all information
about that ship appears. The figure shows
this page scrolled down. Press CANCEL to
return to Ship List View. If the ship name
cannot fit in the available space, press OK
to view the name in the Ship data page.
Horizontal scrolling is not available for the
Ship List View. This is a read only page.
The line indicator (underscore character) is
present none the less to facilitate the Info
function if the user presses
INFO. Pressing
EDIT has no effect on read only pages.
