User interface
Man_user_AI80_r2 21
- Write predef. -------
Name:
Message:
Hold [OK] to save
Write predefined
In the Write predefined page only the required data
are available for entry, e.g. the name of the
predefined message and the message text.
*** NEW SMS ***********
4 unread messages
[OK] go to Inbox
[CANCEL] later
New SMS received
When an SMS is received, the user is notified
through a dialogue box that appears on the screen.
Press
OK to read the message immediately or LEFT
ARROW
to delete the dialogue box. The message
can be found in Inbox.
Downperiods
- Downperiods ---- ►
23.May 08:00 - 23.May 08:30
23.May 09:00 - 23.May 09:30
23.May 10:00 - 23.M▼y 10:30
23.May 11:00 - 23.May 11:30
23.May 12:00 - 23.May 12:30
This page shows the last ten downtimes (start
and stop) for the Base Station on the format
DD/MM hh:mm - DD/MM hh:mm. It is a read
only page. Press CANCEL to return to Main
Menu.
Channel Management
- Chn.Mngt ---------
View Regions
Add Region
Edit Current region
In the Chn. management menu the user can choose
between editing current region, viewing all regions or
adding a new region.
- Regions -----------
REGION 1
REGION 2
REGION 3 ▼
REGION 4
View regions
In this page all regions (max 8) are shown. This is a
read only page. Use UP/DOWN ARROW to select the
region of interest. The figure shows a list with three
regions.
