Simrad AI80 User Manual

User interface
Man_user_AI80_r2 17
Settings
- Settings ----------
Nav.Status
Voyage related
Gyro calibration
Static data ▼
VHF
LR
Serial
PIN
From the Main Menu, select Settings, press OK and
the Settings page appears.
All parameters that can be edited are found here. The
INFO button provides the user with additional
information about each menu item.
In the Settings main menu the user can choose
between Nav.Status, Voyage related, Gyro
calibration, Static data, VHF, LR, Serial or PIN.
Editing parameters in these pages is always protected
with a PIN-code.
To save edited parameters, press the OK button.
- Nav.Status --------
NavStatus: MOORED
Nav.Status
In this page the user can set the appropriate navigation
status. Choose from predefined list.
- Voyage related ----
Dest: Not defined
ETA: 24100730
OnBrd: 71 ▼
Draught: Not defined
Type: 123
Voyage related
All voyage related settings can be viewed and altered
in this page.
- Gyro calibration -►
Corrected heading: 9°
Gyro calibration
If a stepper or syncro gyro is used for heading input,
the heading can be calibrated here. This is done by
entering the actual heading. Ensure constant heading
when entering correction.
