Simrad GC80 User Manual

Simrad GC80/85 Double System Controller
988-12721-001
59
SWITCH DEFAULT FUNCTION DESCRIPTION
S11-1
OFF
NO.1 gyrocompass serial
output setting
Output port: DGCIF board, TB21"13TX+/-", NO.1
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S11-2
OFF
NO.1 gyrocompass serial
output setting
Output port: DGCIF board, TB21 "14TX+/-", NO.1
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S11-3
OFF
NO.1 gyrocompass serial
output setting
Output port: DGCIF board, TB21 "15TX+/-", NO.1
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S11-4
OFF
NO.1 gyrocompass serial
output setting
Output port: DGCIF board, TB21 "16TX+/-", NO.1
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S11-5
OFF
NO.1 gyrocompass serial
output setting
Output port: DGCIF board, TB21 "17TX+/-", NO.1
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S11-6
OFF
NO.1 gyrocompass serial
output setting
Output port: DGCIF board, TB21 "18TX+/-", NO.1
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S11-7
OFF
NO.1 gyrocompass serial
output setting
Output port: DGCIF board, TB22 "19TX+/-", NO.1
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S11-8
OFF
NO.1 gyrocompass serial
output setting
Output port: DGCIF board, TB22 20TX+/-", NO.1
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S12-1
OFF
NO.1 gyrocompass serial
output setting
Output port: DGCIF board, TB22 "21TX+/-", NO.1
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S12-2
OFF
NO.1 gyrocompass serial
output setting
Output port: DGCIF board, TB22 "22TX+/-", NO.1
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S12-3
OFF
NO.1 gyrocompass serial
output setting
Output port: DGCIF board, TB22 "23TX+/-", NO.1
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S12-4
OFF
NO.1 gyrocompass serial
output setting
Output port: DGCIF board, TB22 "24TX+/-", NO.1
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
