Simrad GC80 User Manual

Simrad GC80/85 Double System Controller
988-12721-001
61
SWITCH DEFAULT FUNCTION DESCRIPTION
S22-1
OFF
NO.2 gyrocompass serial
output setting
Output port: DGCIF board, TB22 "21TX+/-", NO.2
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S22-2
OFF
NO.2 gyrocompass serial
output setting
Output port: DGCIF board, TB22 "22TX+/-", NO.2
OFF = IEC61162-1 ed.2 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S22-3
OFF
NO.2 gyrocompass serial
output setting
Output port: DGCIF board, TB22 "23TX+/-", NO.2
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S22-4
OFF
NO.2 gyrocompass serial
output setting
Output port: DGCIF board, TB22 "24TX+/-", NO.2
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S22-5
OFF
NO.2 gyrocompass serial
output setting
Output port: DGCIF board, TB23 "25TX+/-", NO.2
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S22-6
OFF
NO.2 gyrocompass serial
output setting
Output port: DGCIF board, TB23 "26TX+/-", NO.2
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S22-7
OFF
NO.2 gyrocompass serial
output setting
Output port: DGCIF board, TB23 "27TX+/-", NO.2
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
S22-8
OFF
NO.2 gyrocompass serial
output setting
Output port: DGCIF board, TB23 "28TX+/-", NO.2
OFF = IEC61162-1 ed.4 output (4800 bps)
ON = IEC61162-2 ed.1 output (38400 bps)
Note! Settings for S21 and S22 must be set identically to S11 and S12.

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
