Simrad GC80 User Manual

Simrad GC80/85 Double System Controller
988-12721-001
63
SWITCH DEFAULT FUNCTION DESCRIPTION
S2-1 OFF
Data output for record
(Not used)
SW2-1 OFF
No output
SW2-2 OFF
SW2-1 OFF
Output for old monitor
SW2-2 ON
S2-2 OFF
SW2-1 ON
Output for new monitor
SW2-2 OFF
SW2-1 ON
No output
SW2-2 ON
S2-3 OFF
Operating panel type
OFF = GPANEL (NOT FOR BAMS)
ON = GPANEL-A (FOR BAMS)
S2-4 OFF Pendulum ferry Not used
S2-5 OFF
Serial signal transmit
frequency IEC61162-1
ed.4
SW2-5 OFF
= 1 sec (1 Hz)
SW2-6 OFF
SW2-5 OFF
= 100 msec (10 Hz)
Note: If selecting 38400 baud
rate for the serial out the output
frequency will be:
50 Hz for HDT/THS and
50 Hz for ROT.
SW2-6 ON
S2-6 ON
SW2-5 ON
= 200 msec (5 Hz)
SW2-6 OFF
SW2-5 ON
= Invalid
SW2-6 ON
S2-7 OFF Not used
S2-8 OFF
System select
information contact
OFF = No ON = Yes
S3-1 OFF Timer startup OFF = No ON = Yes
S3-2 OFF
Talker ID of “ROT”
sentence
OFF = “HE” ON = “TI”
S3-3 ON
Rate of turn scale
SW3-3 OFF
Max 30.0 °/min.
SW3-4 OFF
SW3-3 OFF
Max 300.0 °/min.
SW3-4 ON
S3-4 OFF
SW3-3 ON
Max 120.0 °/min.
SW3-4 OFF
SW3-3 ON
Invalid
SW3-4 ON

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
