Simrad GC80 User Manual

Simrad GC80/85 Double System Controller
64
988-12721-001
SWITCH DEFAULT FUNCTION DESCRIPTION
S3-5 OFF
Ban or permission of a
“ROT” sentence output
Not used
3-6 ON For Simrad use
OFF = Not used
ON = Simrad GC type (80 or 85) shown in display
at start-up according to S1-2 setting.
S3-7 OFF Not used
S3-8 OFF
Buzzer stop output/
Running contact
output
OFF = Running contact enabled
ON = Buzzer stop enabled
S4-1 OFF
Not used - Factory
operation
S4-2 ON
For Double System or
not
OFF = Standard
ON = Double
S4-3 OFF Not used
S4-4 OFF Alarm detection time
OFF = 300 ms
ON = 2 sec
S4-5 OFF Enable/disable THS
OFF = HDT
ON = THS
S4-6 ON
For Double system or
not
OFF = Standard
ON = Double
Jumper settings on SCC boards
JUMPER DEFAULT FUNCTION DESCRIPTION
J5
(RESET)
Open CPU reset Used to reset the CPU
J7
(11TX)
3-4 short
Serial signal output
setting
(DGCT board 11TX)
1-2 Short = TK spec.
3-4 Short = IEC61162-2 ed.1
(38400 bps)
5-6 Short = IEC61162-1 ed.4
(4800bps)
NOTE: Never use both jumpers at the
same time!

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
