JUMPER DEFAULT FUNCTION DESCRIPTION
J8
(12TX)
3-4 short
Serial signal output
setting
(DGCT board 12TX)
1-2 Short = IEC61162-2 ed.1
(38400 bps)
3-4 Short = IEC61162-1 ed.4
(4800bps)
NOTE: Never use both jumpers at the
same time!
J9 1-2 short
Jumper for sensor
selection signal
1-2 short: Normal open Short for
selection
3-4 short: Unused
J10
1-2 short
Jumper for sensor
selection signal
Output port: GTERM-A board,
"RNCN"
1-2 Short = Running "CLOSES",
Stop "OPEN"
3-4 Short = Running "OPEN",
Stop "CLOSES"
NOTE: Never use both jumpers at the
same time!
J11 1-2 short
Not used
Not used
J12 1-2 short
J13 1-2 short
Not used
Not used
J15 Open
Not used
Not used
J16 1-2 short
Not used
Not used

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
