Sirona C3 Plus - Page 23

Sirona Dental Systems GmbH 4 Controls and functional elements
C3
+
4.2 Control panel on the dentist element
59 06 404 D 3390
D 3390.201.01.18.02
23
Main functions – dark blue keys
Quick adjustment keys for speed and
instrument intensity
For electric motors and the SIROSONIC L scaler
Spray ON/OFF
On burr drives
Chip blower
On burr drives
Counterclockwise rotation
For electric motor
Instrument light ON / OFF
Pressing this key for a while displays the light intensity
settings dialog.
Mouth rinsing position chair program
With last position memory function (freely program-
mable)
Chair program 0
Entry / exit position (freely programmable)
Chair programs 1 and 2
(freely programmable)
IMPORTANT
The four program keys are also used for reprogramming
the chair programs.
A
%
INSTR. LIGHT
SS
00
22
11
