4 Controls and functional elements Sirona Dental Systems GmbH
4.2 Control panel on the dentist element C3
+
59 06 404 D 3390
24 D 3390.201.01.18.02
Additional functions – light blue keys
Preselection of user A or B
All instruments must be in place.
You cannot switch between the two users after picking
up an instrument
.
Saving instrument settings
The instrument to be programmed must have been
picked up.
X-ray image viewer ON / OFF
SIVISION 3 also has WHITE SCREEN activation
Composite key ON/OFF
For operating light, reduced light intensity for composite
fillings
Operating light ON / OFF
For normal light intensity
Pressing and holding this key displays the light intensity
settings dialog:
OPERATING LIGHT
Tumbler filling
Pressing and holding this key displays the settings
dialog:
CUP FILL TIMER
Flushing of the cuspidor
Pressing and holding this key displays the settings
dialog:
BOWL FLUSH TIMER
Freely selectable function
e.g. call key, always functions as button
Freely available relay 230 V, 6 A
(connected by the service engineer).
Freely selectable function
The function can be preset as a button or switch in the
Mode dialog.
Freely available relay 230V, 6 A
(connected by the service engineer).
A/B
A
%
OPERATING LIGHT
A
CUP FILL TIMER
A
BOWL FLUSH TIMER
