12 Assistant element Sirona Dental Systems GmbH
12.5 Satelec Mini LED curing light C3
+
59 06 404 D 3390
80 D 3390.201.01.18.02
4.3 Pulsed curing mode
This mode is selected by pressing the function button.
The light operates at full power in "pulsed" mode; it emits
radiation in 10 consecutive light pulses of 1s each.
There is a 250 ms break between the individual pulses.
LED 4.3 shows your selection.
4.4 "Soft start" mode
This mode is selected by pressing the function button.
The "soft start" mode provides:
• A 10-second "soft start" from 0 to 1,100 mW/cm², or
from 0 to 2,000 mW/cm² with the (optional) "booster
light guide", dia. 5.5 mm.
• Full power during 10 seconds.
LED 4.4 shows your selection.
Handling
After you switch on the treatment center, the Mini L.E.D.
is by default in the quick curing mode (4.2).
If you change the operating mode of the Mini LED while
the treatment center is in operation, the new mode
remains valid even after the Mini LED is placed in its
holder.
After you have selected a mode, the Mini LED is ready
for operation.
Position the light guide as close as possible to the com-
posite material surface you want to photopolymerize.
Make sure that the light guide never touches the material
to be cured, as this may cause damage to the light guide
and reduce its effectiveness.
• Never work without the glare shield (5).
• Never look into the light which is reflected by the
tooth surface.
To start the polymerization cycle, briefly press the ON /
OFF switch (6). This is confirmed by an audible signal.
In each mode, an audible signal sounds every
5 seconds.
The end of the cycle is also indicated by an audible sig-
nal. You may interrupt the cycle at any time though by
lightly pressing the ON / OFF switch.
