Procedure 6: To slide a shelf clip up and down
1. Pull the shelf clip tab up and slide the shelf clip
up or down as required.
2. Once in position, ensure the shelf clip is locked
into place.
Procedure 7: To remove a shelf clip
1. Pull the shelf clip tab up.
2. Twist the top of the clip clockwise off the shelf support strip.
Shelf clip
Tab
Procedure 8: To reposition a standard shelf
1. Unload the shelf and remove it from the cabinet.
2. Slide each shelf clip to the new position in the shelf support strips.
3. Replace the shelf back in the cabinet, and sit it on the shelf clips.
