Spare Parts
Service Manual
SKOPE BME-N ActiveCore
Main Assembly – BME1200N-A Series
1
4
3
2
Table 11: Parts – Main assembly: BME1200N-A series
No. Description Page
1
Cabinet assembly Page 47
2
Door assembly Page 49
3
Sign assembly Page 50
4
Cartridge assembly
Page 51
