SKOPE BME-N ActiveCore
Replacement Procedures
Service Manual
Table 6: Lighting fault diagnostics
Problem Possible cause Repair
No lights working.
Cabinet is dark.
Lights switched off.
Switch the lights on via the electronic
controller faceplate (see page 12), or the
app.
Controller is in Energy Saving
mode.
Open the door to bring the controller into
Normal mode.
Controller alarm. Check the controller for the alarm code.
Plug not connected properly.
Check and clean the plugs on top of the
cabinet.
Light power supply fault. Replace the light power supply.
Light component not
working.
Plug not connected properly.
Check and clean the plug connection in
the side light channel, behind the loom
cover.
Faulty light. Replace the light.
Segment of light not
working.
Faulty light. Replace the light.
Procedure 14: To replace an interior light component
1. Disconnect the cabinet from the mains power supply (see page 22).
2. Unplug the light, and remove the light from the plastic casing.
3. Clip the replacement light into place on the plastic casing, ensuring the male end of the light is at
the bottom, and plug the light in.
4. Ensure the light is firmly and completely clipped in.
5. Reconnect to the mains power supply and check for correct operation.
Procedure 15: To replace the light power supply
1. Disconnect the cabinet from the mains power supply (see page 22).
2. Remove the front panel to gain access to the refrigeration cartridge compartment. If required (one
door models), remove the refrigeration cartridge (see page 31).
3. Remove the light power supply.
4. Replace the light power supply and reassemble.
Procedure 16: To replace an interior wiring loom
1. Disconnect the cabinet from the mains power supply (see page 22).
2. Unplug the light from the wire loom.
3. Gain access to the light power supply (see procedure above).
4. Unplug the wiring loom from the light power supply, and if applicable the sign light.
5. Remove the loom by pulling it through the hole in the cabinet interior base.
6. Refit the new loom and reassemble. Ensure that:
• all plugs are clean, correctly fitted and plugged in.
• the hole is completely sealed with putty.
