48
Spare Parts
Service Manual
SKOPE BME-N ActiveCore
Note: Check the part colour before ordering. If the colour differs from the list above, state the
specific colour when ordering.
*If key lock/s are fitted, please contact SKOPE for a part number.
14 Top hinge – right hand HB0070110582
15 Top hinge – left hand HB0070110583
16 Top hinge spacer B15RW/115
17 Door lock bracket – cabinet piece HB0070111623
18 Rear castor HB0070105066
19 Front castor – lockable HB0070105065
20 Bottom shelf support bracket HB0070110664
21 Mains electrical box assembly HB0070833872
22 Light power supply ELZ11887
23
Cartridge rear stop
SM60BV/327
24 Light holder – no notches HB0070208596
25 LED light bar – 1370 mm ELL11799
Table 13: Parts – Cabinet assembly BME1200N-A series (continued)
No. Description SKOPE Part No.
Unpainted/standard Colour: White Colour: Black
