Spare Parts
Service Manual
SKOPE BME-N ActiveCore
16
Cartridge electrics box enclosure
HB0070207014
–
Electrical box assembly – ActiveCore R290 Fridge (not shown) HB0070833377
17 Cable clamp HB0070206127
18
Cartridge electrics box enclosure rear
HB0070207013A
19
Cartridge plastic bottom
HB0070206212B
20 Hold down bracket HB0070110815A
21 Compressor – Wanbao FN90M HB0074000848
22 Control temperature probe HB0070400542
23 Evaporator temperature probe HB0070400506
24 Evaporator box HB0070510928A
25 Evaporator coil HB0070702232
26
Cartridge plastic top cover
HB0070206133
27
Cartridge gasket seal 2306 mm
PLE11052-2306
28
Cartridge gasket seal 1571 mm
PLE11052-1571
–
Ambient temperature probe (not shown) HB0070401693A
–
Mains power cord (not shown) HB0070400636
–
Controller wire loom – blue (not shown) HB0070401063
–
Controller wire loom – red (not shown) HB0070401062
–
Controller wire loom – white (not shown) HB0070401111
Table 17: Parts – Cartridge assembly (continued)
No. Description SKOPE Part No.
