Getting Started
Channel and Band Selection X2D Multiband
Manually select your radio settings, band, channel, and power frequency to avoid congestion from other signals.
These are six bands and corresponding channels:
Step 1 - Select the INFO menu
Step 2 - Select your drone name
Step 3 - Select the Radio menu and the Band Selection tab to choose the radio band
Step 4 - Select the Radio menu and select a Channel
• Band M1 - 1.6 GHz / channels 1700-1725 MHz
Due to GPS interference vehicle altitude is limited to 33 ft (10 m) above launch (AGL).
• Band M2 - 1.8 GHz / channels 1780-1850 MHz
• Band M5 - 2.0 GHz / channels 2020-2110 MHZ
• Band M3 - 2.2 GHz / channels 2200-2300 MHz
• Band M4 - 2.3 GHz / channels 2301-2390 MHz
• Band M6 - 2.4 GHz (default) / channels 2400-2500 MHz
Channel and Bandwidth Selection X2D 1.8 GHz
To select bands and channels:
Step 1 - Select the INFO menu
Step 2 - Select your drone under Devices
Step 3 - Select Radio
Step 4 - Select Channel Bandwidth Selection
4 MHz Bandwidth
• Channel 3 (1813) MHz - Channel 57 (1867) MHz
8 MHz Bandwidth
• Channel 4 (1814) MHz - Channel 56 (1866) MHz
Step 5 - Select Finish
