1. Chassis
2. Navigation camera (6)
3. Gimbal
4. Motor pod (4)
RGB/IR/Strobe navigation lights
5. Propeller hub
6. Propeller blades
clockwise (6) counter-clockwise (6)
7. Arm (4)
8. Arm clamp (4)
9. Antenna(s)
4
10. microSD card ports & seal
11. USB-C port & seal
12. Cooling outlet (2)
do not cover
13. Hard stop (4)
14. Battery
15. Gimbal isolator (3)
16. Power button
Overview
Skydio Hardware
13
16
11
14
15
12
