Skydio X2D INTL - Operator Manual © 2023 Skydio, Inc. All rights reserved.
Flight
Flight screen
Battery
indicator
Map view
Return location
Recording
Indicator
Skill Settings
Skills Menu
Telemetry
Launch/Land
Camera settings
Connection
status
Device settings
menu
Picture in Picture (PIP)
X2D Color/Thermal
Only
Reference flight telemetry data in the top left corner of the live camera feed.
• Speed of your drone
• Distance from Controller
• Distance from Launch
• Elevation above ground level (AGL)
• Compass Heading in degrees ranging from 0° - 359° and cardinal directions
• Gimbal Pitch -90° to 90°
Telemetry
