Maintenance
Step 2 - Remove the damaged hard stop(s)
• Extend the arm that is either above or below the arm with
the damaged hard stop
• Leave the arm with the damaged hard stop folded in
• Loosen the hard stop screw using the T3 driver
• Remove the screw
Step 1 - Identify the damaged hard stop
• Rotate the hard stop so the flange protrudes from
the drone
• Grab the hard stop by the flange and pull out to
remove - rotate the hard stop back and forth to
dislodge it from the drone
Replace hard stops
