SMC Networks LECSA Series User Manual

- 17 -
4.3 Speed control mode
(1) [Basic settings parameters (No.PA□□)]
No.
Symbol
Name
Initial value
Unit
PA08
ATU
Auto tuning mode
001h
PA09
RSP
Auto tuning response
6
(2) [Extension setting parameters (No. PC□□)]
No.
Symbol
Name
Initial value
Unit
PC01
STA
Acceleration time constant
0
ms
PC02
STB
Deceleration time constant
0
ms
PC05
SC0
Internal speed command 0
0
r/min
PC06
SC1
Internal speed command 1
100
r/min
PC07
SC2
Internal speed command 2
500
r/min
PC08
SC3
Internal speed command 3
1000
r/min
PC31
SC4
Internal speed command 4
[Applied]
200
r/min
PC32
SC5
Internal speed command 5
[Applied]
300
r/min
PC33
SC6
Internal speed command 6
[Applied]
500
r/min
PC34
SC7
Internal speed command 7
[Applied]
800
r/min
4.4 Torque control mode
(1) [Extension setting parameters (No. PC□□)]
No.
Symbol
Name
Default
Unit
PC01
STA
Acceleration time constant
0
ms
PC02
STB
Deceleration time constant
0
ms
PC05
SC0
Internal speed limit 0
0
r/min
PC06
SC1
Internal speed limit 1
100
r/min
PC07
SC2
Internal speed limit 2
500
r/min
PC08
SC3
Internal speed limit 3
1000
r/min
PC31
SC4
Internal speed limit 4
[Applied]
200
r/min
PC32
SC5
Internal speed limit 5
[Applied]
300
r/min
PC33
SC6
Internal speed limit 6
[Applied]
500
r/min
PC34
SC7
Internal speed limit 7
[Applied]
800
r/min
