5.7 Positioning (Point Table) Operation using the Setup Software
This feature is only available in positioning (point table) mode.
When positioning using the positioning (point table) mode, the point table (target position, speed data, acceleration time,
deceleration time etc.) must be configured.
5.7.1 Point table List
① Using the “Positioning Data” menu in the setup software. The “Point table list” can be opened by selecting “Point
Table”
② “Read” ： point table data will be read from the LECSA and displayed.
③ “Write All”： point table data will be written to the LECSA.
①
②
③
