Chapter 12 Data Manager Operations
The Data Manager is used to store, sort, and review saved files. Most operations are controlled
through the toolbar.
12.1 Screen Layout
Select Data Manager on the Module toolbar to open the file system. Use the toolbar at the top of
the screen to navigate through the data. The folders panel below the toolbar displays the contents
of the Windows My Documents > ShopStream folder, which is the Data Manager main screen. The
information panel on the lower-left portion of the screen shows a summary of the saved file when
available, and the preview panel on the lower right displays an image if the selected file is a
graphic.
1— Data Manager Toolbar
2— Folders Panel
3— Preview Panel
4— Information Panel
Figure 12-1 Sample Data Manager main screen
The main screen includes folders for saved files from the various modules:
• Camera Folder—contains photographs taken with the built-in camera. See Image Viewer on
page 166.
• CTM Data Folder—contains files saved while working in the Guided Component Test
module.See Scope Viewer on page 165.
• Sample Files—contains an assortment of example saved data files.
• Scanner Data Folder—contains files saved while working in the Scanner function. See
Scanner DataViewer Operation on page 155.
1
2
3
4
