Data Manager Operations Vehicle System Report Data Folder

12.6 Vehicle System Report Data Folder

The Vehicle System Report Data Folder contains saved Code Scan (trouble code) files.

12.6.1 Vehicle System Report Data

Selecting the Vehicle System Report Data folder opens a list of the saved Code Scan (trouble

code) files.

To view a file, select it and use Adobe Reader to view and, or print the PDF file.

The following example (Figure 12-17) shows a typical Vehicle System Report title page.

Figure 12-17

SampleShop

Your Address

Your City,

Your Phone Number

Vehicle System Report

EHICLE INFORMATION

VIN KT6

YEAR 2002

MAKE Ford

MODEL Mustang

ENGINE 4.6L V8 EFI

SYSTEM

2002 Mustang 4.6L V8 EFI

CODE SCAN RESULTS

Systems Analyzed: 20

Engine All Powertrain Codes Codes: 4

Transmission All Powertrain Codes Codes: 4

Antilock Brakes Codes: 0

Airbag Codes: 0

Body Control Module Codes: 0

Door Module Driver Codes: 0

Door Module Passenger Codes: 0

Heating & Air Conditioning Codes: 0

Rear Auxiliary Climate Control Codes: 0

Rear Heating & Air Conditioning Codes: 0

Instrument Panel Cluster Codes: 0

Passenger Presence System Codes Codes: 2

Radio Codes: 0

Seat Module Codes: 0

Suspension (ESC) Codes: 0

Theft Deterrent Codes: 0

Tire Pressure Monitor Codes: 0

Date: 1/11/2017

OBDII Codes: 4

Engine All Powertrain Codes Codes: 4

P0101

| Mass Air Flow Circuit Out Of Range

P0455

| EVAP System Leak (Large)

P0171

| Fuel System Too Lean Bank 1

P0420

| Catalyst Efficiency Low Bank 1
