168
Chapter 14 System Settings Operations
Selecting System Settings from the Home screen opens a menu with two options:
• Paired Devices - Paired Devices allows you to check the status and pair wireless devices to
the diagnostic tool.
• Shop Information - Shop Information allows you to create and edit a personalized header that
is included on printed documents.
• Data Backup - Data Backup provides two options, backup and restore.
14.1 Paired Devices
Wireless devices, such as the Scan Module, and optional M2 Scope/Meter communicate
wirelessly with the diagnostic tool to allow you work and access data remotely while working on a
vehicle. These devices need to be paired, or synchronized, the first time they are used together.
Other devices, such as the M4 Scope Module are paired using a USB connection.
14.1.1 Checking Paired Devices
z To check the devices paired to your diagnostic tool:
1. Select System Settings > Paired Devices.
The paired devices screen opens (Figure 14-1).
The Paired Devices screen lists all of the devices paired to the diagnostic tool, and also indicates
whether or not there is active communication occurring.
Figure 14-1 Typical Paired Devices screen
14.1.2 Scan Module Pairing
For Scan Module pairing procedures, see Pairing The Scan Module on page 59.
14.1.3 M4 Scope Module Pairing
For M4 Scope Module pairing information, see M4 Scope Module Pairing on page 93.
4$01&.0%6-&.
4$"/.0%6-&
