Introduction Features and Specifications
2.1.2 Scope Module
1— Auxiliary (DB9) Connector
2— Channel 4 Jack
3— Channel 3 Jack
4— Channel 2 Jack
5— Channel 1 Jack
6— Common (Ground) Jack
7— USB Jack (not shown - used for remote operation)
Figure 2-3 Scope Module, removed from Diagnostic Tool
